Click on small image to enlarge
|
| Reference Number | 5598
|
| Vessel Type | Liners - Bottom & Surface, Troller
|
| Built By | Alan Barnett Fishing
|
| Year Built | 2003
|
| LOA | 17.5 m
|
| Beam | 5.7 m
|
| Draft | 2 m
|
| Construction | Steel
|
| Construction Details | 6mm Plate
Wheelhouse is steel construction with aluminium framed windows with toughened safety glass.
Bilge tank and fuel plumbing all 316 SS
|
| General Description | SURFACE LONG LINE & TROLLER
|
| Engine Details | Iveco 8210 SRM36 330HP
Keel cooled.
21,000 hours since Overhaul 2017
|
| Auxiliary Engine | Isuzu - 20kVA generator
Cummins 6BT 5.9-C. 3152 hours since installed 2017
- drives hydraulics for scallop winch
|
| Electrical | 415V, 240V. 12/24V. Shore power
|
| Gearbox | Twin Disc MG5091DC 4.5:1
|
| Propeller | 4 blade
|
| Steering | Twin Ram Hydraulic/electric
2 stations
|
| Fuel Capacity | 12,400L , 3 Tanks
|
| Water Capacity | 4.400L , 1 Tanks
|
| Max Speed | 10 knots
|
| Service Speed | 9 knots
|
| Fuel Consumption | 18-20 lph
|
| Hold | 45 m3
|
| Hold Type | Live Well, RSW, Freezer
|
| Hold/Fishroom | Original wet wells opened up and incorporated into one large fish room with stainless steel floor.
Forward 75% of fish room refrigerated with coils, GRP walls & ceiling.
Aft 25% of fish room divided into 3 pounds with stainless steel walls, ceiling & floor. Ice maker feeds ice into these 3 pounds (each pound 2.5-3 tonnes).
The whole fish room will take 21 tonnes albacore.
Stern bait freezer 7.14 cubic metres. Can also be used for fish bins/frozen product if needed.
|
| Freezer Plant | Bitzer 3 phase compressor R134A
Ice machine
|
| Accommodation | 4 Bunks in Fo'c's'le
Skipper cabin in wheelhouse
|
| Galley | Electric stove
Fridge/freezer
Microwave
Table & seating
Built in cupboards
Sink & Pressurised water system
|
| Facilities | TV & Video
Toilet & Shower with hand basin
Electric hot water
Captain Chair.
|
| Pot Hauler | Hydraulic
|
| Line Hauler | Moana 50 mile long line drum
|
| Gear | Tuna poles
|
| Cargo Winch | Lifting boom with slewing & topping winches
|
| Anchor | Hydraulic Winch
Plough 70kg
Rockna 70kg
|
| Radio | SSB - Icom IV-M710
VHF - GME G-Com
VHF - Icom IC-M710
|
| Radar | Furuno 1832 RDP-118
|
| G.P.S. | Furuno GP32
|
| Plotter | Furuno
Max C
|
| Sounders | Furuno FCV-1200L
|
| Auto Pilot | Simrad AP35
|
| Other | MaxSea-Nobeltec TIMEZERO Ver 4.1
AIS - Class B transponder Icom MA-500TR
6 person life raft
EPIRB Float free
|
| Survey Class | MNZ Survey
Limits - Fishing - Offshore 200 miles NZ & Chatham Islands
Date of Expiry 15/11/2030
MARPOL Annex VI compliant
|
| Price | NZ$ 1,200,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
