| Reference Number | 5579
|
| Vessel Type | Trawler
|
| Built By | Damen Shipyards, Gorinchem, Holland
|
| Year Built | 1979
|
| LOA | 26 m
|
| Length Reg | 24.95 m
|
| Beam | 7 m
|
| GRT | 156.7 T
|
| Construction | Steel
|
| General Description | Fresh Fish Stern Trawler
|
| Engine Details | Cummins KT38MO 625kW
Hours 32,403 (13 June 2023)
|
| Auxiliary Engine | Cummins 6BT5.9-D(M) 91kW
Hours 20,406 (13 June 2023)
|
| Electrical | 100 kVA generator
|
| Gearbox | Reinjes
|
| Propeller | fixed blade
|
| Steering | Electric/hydraulic
|
| Bollard Pull | 12 tonnes
|
| Fuel Capacity | 33,000 litres in 2 tanks
|
| Water Capacity | 11,000 litres in one tank
|
| Max Speed | 10.2 knots
|
| Service Speed | 9 knots
|
| Wheel House | The wheelhouse is situated forward of amidships on the raised foredeck. There is good all round visibility.
|
| Hold | 38 T
|
| Hold Type | Chiller
|
| Hold/Fishroom | 1350 bins
Lined with stainless steel over poly with rockwool insulation
Refrigerated piped hold - 0.6dC.
|
| Freezer Plant | Ice Maker - Snowkey SFM 30W 3t per 24 hours
Bitzer compressor
|
| Accommodation | 7 berths forward.
Electric cabin heaters
|
| Galley | SS sink
Domestic Electric range
Microwave oven
Fridge
Freezer
|
| Facilities | Hot water
Toilet
Shower
Saloon table with seating
Air conditioning
|
| Winch Details | Thyboron winch system new April 2020
Hydraulic split winches
50 tonnes pull
Capacity 1500m x 16mm cable
2 x Gilson winches
Truck deck sorting table new 2020
|
| Net Drum | Hydraulic net roller new 2020
|
| Gear | 2 x Scraper trawls 50m
2 x Kiwi doors 2.75m2
Bridles
|
| Cargo Winch | Electric JIB 1,000kg capacity
|
| Anchor | Electric windlass
2 x Danforth anchors
|
| Radio | SSB Furuno FSB-1552
VHF Icom ICM59
VHF Icom ICM4236
|
| Radar | Furuno 36 mile
|
| G.P.S. | Furuno GP33
|
| Plotter | Seaplot
MaxSea
|
| Sounders | Furuno FCV1150
|
| Auto Pilot | Furuno FAP-330
|
| Net Monitor | Marport
|
| Other | TMQ rudder angle
Victron battery charger
Airlink MP70 cell date backup
Sat phone - Iridium
Triton CLS tracking
AIS Furuno FA-50 Class B
Ezyswitch text alarm monitoring
Printer
Computer
Pioneer AM/FM stereo
Trackvision TV
Swann CCTV cameras x 5
Emergency fire pump - Kohler diesel in steering flat.
Emergency Fire Pump - Electric in engine room
2 x 8 man life-rafts
EPIRB - 406 float free
|
| Survey Class | NZ Certificate of Survey
Limits - NZ Offshore
Date of expiry 28/09/2026
|
| Price | NZ$ 2,500,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
