| Reference Number | 5578
|
| Vessel Type | Trawler
|
| Built By | Damen Shipyards, Gorinchem, Holland
|
| Year Built | 1979
|
| LOA | 26 m
|
| Length Reg | 24.95 m
|
| Beam | 7 m
|
| Draft | 2.5 m
|
| GRT | 156.7 T
|
| NRT | 40 T
|
| Construction | Steel
|
| Construction Details | Light displacement 210 tonnes
|
| General Description | FRESH FISH STERN TRAWLER
|
| Engine Details | Cummins KTA38 new 2017
Hours 25,211 (13 June 2023)
|
| Horsepower | 850 hp
|
| Auxiliary Engine | Cummins 6BT5.9 new 2017
Hours 35,119 (13 June 2023)
|
| Electrical | Alternator 80kVA new 2017
|
| Gearbox | Twin Disc MG5225DC 5.04:1
|
| Propeller | fixed blade
|
| Steering | Electric/hydraulic
|
| Fuel Capacity | 36,000 litres in two tanks in after peak
|
| Water Capacity | 10,000 litres
|
| Max Speed | 10 knots
|
| Service Speed | 9 knots
|
| Wheel House | The wheelhouse is situated forward of amidships on the raised foredeck. There is good all round visibility. Wheelhouse has been completely refitted 2017.
|
| Engine Room | Refitted 2017.
|
| Hold | 40 T
|
| Hold Type | Chiller
|
| Hold/Fishroom | 35 tonnes
1,300 fish bins
Refrigerated -0.0 deg C
|
| Freezer Plant | Ice maker - Snowkey SFM 30W
3t per 24hr - new 2017
|
| Accommodation | Captains Cabin
3 x 2 berth cabins
|
| Galley | Completely refitted 2017
Electric stove
Microwave
Range hood
|
| Facilities | Large table with seating for 7 in mess area
TV
Toilet
Shower
Clothes washing machine
Clothes drier
Heat pump new 2019
All new 2017
|
| Winch Details | Hydraulic split winches 1200m x 16mm cable
3 tonnes Gilson
10 tonnes Gilson
Net roller
New hydraulics
Control system in extended wheel house
Supplied new by Challenge Marine 2017
|
| Gear | Nets - 2 x 150' scraper trawls
Doors - Thyboron Type 16
|
| Cargo Winch | Derek 1 tonne.
|
| Anchor | Hydraulic windlass
Chain
Stockless anchor 230kg
Stockless anchor 235kg
|
| Radio | SSB - JRC JSB 196 SSB Radio new 2017
VHF - GME - new 2017
VHF - Icom ICM58
HF - Icom ICM710
|
| Radar | JRC JMA 3334 Colour Radar
19 Inch Philips monitor
New 2017
|
| G.P.S. | JRC JLR GPS system
DM24 Data multi plexer
new 2017
|
| Plotter | Olex 3D Chart Plotter. Computer, Oex AIS interface.
North & South Island Charts
19 Inch Philips monitor
new 2017
SeaPlot Pro
|
| Sounders | JRC JFC 130BB 38/200 Khz
19 Inch Philips monitor
new 2017
Furuno FCV 1150
|
| Auto Pilot | Furuno NavPilot 711C
|
| Net Monitor | Marport Catch sensors
Marport Door sensors
Marport Head Line sensors
|
| Other | 2 x 19 Inch Philips monitors
UPS On Line tracking
New 2017
Furuno intercom
Swann video monitor
AIS Simrad V3100 Class B
Fire Suppression System SPA
Smoke alarm engine room
Emergency fire pump engine room - electric
Emergency fire pump steering flat - Kohler diesel
STABILISER fins new 2017
EPIRB 406 float free
2 x 6 man life-rafts
|
| Survey Class | NZ Certificate of Survey
Offshore - Within 100 miles of the coast of New Zealand
Date of Expiry 30/10/2026
|
| General | The vessel given a substantial refit in 2017 including new main engine, winches, hydraulics, wheel house, galley saloon
|
| Price | NZ$ 2,500,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
