| Reference Number | 5542
|
| Vessel Type | Liners - Bottom & Surface
|
| Built By | Jrou-Ryou Shipbuilding, Japan
|
| Year Built | 1992
|
| LOA | 35 m
|
| Length Reg | 34.5 m
|
| Beam | 6.5 m
|
| Draft | 3.4 m
|
| GRT | 138 T
|
| Construction | Steel
|
| General Description | TUNA LONGLINER RSW TANKS - WESTERNISED EX JAPANESE
|
| Engine Details | Niigata 6M6-22HX
|
| Horsepower | 700 hp
|
| Auxiliary Engine | 2 x Niigata 6NSF
|
| Electrical | 2 x Taiyo 150kVA
|
| Gearbox | Nico MGN-1524V 4:1
|
| Propeller | 4 blade fixed pitch
|
| Shaft Size | 800 mm
|
| Steering | Hydraulic 2 station Gyro
|
| Fuel Capacity | 80,000 litres in 7 tanks = 60 days @ 8.7 knots
|
| Water Capacity | 22,300 litres in 2 tanks
De-desalination plant 3,000 litres per day
|
| Max Speed | 13 knots
|
| Service Speed | 8.75 knots
|
| Fuel Consumption | 1400 lpd steaming
1000 lpd working
|
| Wheel House | Midships
|
| Engine Room | Aft
|
| Hold/Fishroom | 7 RSW fibreglass tanks total 45.91m3 0 degC in brine down to -18deg dry
Hangs 18 tonnes fish
1 x 8 tonnes -20deg freezer bait room port side
|
| Freezer Plant | Nissan auto glycol
Automatic temp control
#2 & #3 compressors rebuilt July 2009
|
| Accommodation | 1 x 8 berth
3 x 4 berth
Skippers cabin 2berth
|
| Galley | Westernised
Well appointed
|
| Facilities | Hot water
2 x toilets
1 x Shower
Full headroom throughout.
Fully ducted air conditioning - overhauled & new compressor 2018
|
| Line Hauler | Hamilton long line drum 40 miles mono
Shooter
2 x snood haulers
2,000 leaded swivels
Stainless steel snaps
Tuna circle hooks
8 beacons
Linemaster GPS beacon system
|
| Cargo Winch | Yes
|
| Anchor | Yes
|
| Radio | SSB Furuno FT155
VHF
|
| Radar | Raymarine & Raymarine AIS
|
| G.P.S. | Furuno GP500 Mk II
Furuno GP30
|
| Plotter | C Plot
|
| Sounders | Furuno FCV1150
|
| Auto Pilot | Tokyo Keiki 2000
|
| Other | Iridium sat phone
Extensive auxiliary machinery
Hydraulic windlass - single gypsy with 300mm warping drums
1 x JIB crane 1.5 SWL deck crane Tanado
Zodiac tender
SS hydraulic elevator running forward
Mooring vcapstan winch aft deck (electric)
|
| Survey Class | Unlimited Ocean Going
Full survey renewed June 2021
|
| General | New aft awning with fibreglass roof
|
| Price | AU$ 1,300,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
