| Reference Number | 5487
|
| Vessel Type | Liners - Bottom & Surface, Trawler
|
| Designed By | Breekvelt
|
| Built By | Primrose Engineering, Gisborne
|
| Year Built | 1979
|
| LOA | 17.55 m
|
| Beam | 5 m
|
| Draft | 2.1 m
|
| GRT | 58.13 T
|
| NRT | 31.18 T
|
| Construction | Steel
|
| Construction Details | Steel hull & deck house
|
| General Description | COASTAL TRAWLER ALSO SET UP FOR LINE FISHING
|
| Engine | Detroit
|
| Engine Details | 6V/92 TI Series D-Dec
291hp @ 1800rpm
2014 Installed as a fully rebuilt engine ex Transmission & Diesel. Vessel then not used for some time until eventually sold.
Exact hours run not known.
Exhaust & muffler new 2024
|
| Horsepower | 291 hp
|
| Electrical | Victron Inverter/charger new 2023
House & radio batteries new 2025
Start batteries new 2025
Wiring upgrades ongoing
|
| Gearbox | Allison MH 4.5:1 reduction
|
| Propeller | 54'X 37" 4 blade in Kortz nozzle - new 2021
|
| Fuel Capacity | 10,000 litres in 3 tanks
2 x 3,000 litres port & starboard in engine room
1 x 4,000 litres in forepeak
|
| Water Capacity | 500L
2 tanks
|
| Max Speed | 9 knots
|
| Service Speed | 8 knots
|
| Wheel House | Aft
|
| Engine Room | Under wheelhouse
|
| Hold | 25 T
|
| Hold Type | Ice
|
| Hold/Fishroom | Squared for 400 bins
|
| Accommodation | 3 berths in aft of wheelhouse
|
| Galley | Stainless steel Sink bench unit
LPG 4 burner stove with oven
Domestic fridge
table & seating for 4
|
| Facilities | Toilet, shower and hand basin
Hot water cylinder in engine room heated by engine
|
| Winch Details | Forward of w/house
Holds 1000M X 13mm warp per side
|
| Net Drum | 1 x trawl net roller
|
| Line Hauler | Hyd bottom L/L drum
Surface long line drum
|
| Gear | All trawl gear + bottom line gear
|
| Anchor | 1 x 100kg high holding stockless anchor
40m x 20mm chain and 40m 25mm warp
1 x 90kg plough. Could use trawl wires
Uses trawl winch
|
| Radio | Uniden VHF
Sound system & CD
|
| Radar | Furuno GD 188 Nav-net C-Map
|
| G.P.S. | Furuno GP 36
|
| Plotter | TimeZero on Computer
FurunoGD 188 Nav-net C-Map
|
| Sounders | Furuno 581
|
| Auto Pilot | Furuno FAP7002
|
| Other | 4 man liferaft
EPIRB 406
|
| Survey Class | Maritime NZ Certificate of Survey
Limits - Offshore 100M including Chatham Islands
Category - Fishing - Trawling, Bottom longline, Potting
Date of expiry - 2030
|
| General | Recent extensive upgrade.
|
| Price | NZ$ 250,000.00
Plus GST and /or Taxes if any.
|
|
