Maritime International: Maritime International

Reference Number

5476

Vessel Type

Trawler

Built By

Germany

Year Built

1996

LOA

40.8 m

Beam

11 m

GRT

837 T

NRT

262 T

Construction

Steel

Construction Details

DWT 401

General Description

FREEZER STERN TRAWLER. POA

Engine Details

MAN B&W 2610hp 900rpm

Auxiliary Engine

#1 - DEUTZ AG 1 x TBD 616 V12, , 562 kW.
#2 -

Electrical

Shaft generator

Propeller

Nozzle-mounted propeller, 160 rpm, 3100 mm diam.

Bollard Pull

Estimated bollard pull at 5 knots is 16 tons

Fuel Capacity

180 m3

Water Capacity

19.5 m3

Fuel Consumption

SPEED / CONSUMPTION: abt. 12 knots. Consumption/trawling MGO 6,1 ts/day. Sailing full/slow power abt. 6.1 / 4 ts/day.

Hold

426 m3

Hold Type

Freezer

Hold/Fishroom

426 cbm

Freezer Plant

4 x vertical plate freezers capacity abt. 32 ts/24 hrs. Refrigerant: Ammonia
Plate freezer size: 4 pcs. x 26 sections, 2 block, size block 530x530x 100 mm
2 generators for the freezer system new in 2014-2015. Freezer: changed hoses and valves in 2014

Accommodation

For 19 pers., 1×1 person, 1×1 person (hospital), 5×2 person, 1×3 person and 1×4 person cabins

Winch Details

2 x 27 ts trawl winches
2 x 9,2 ts Gilson winches Rapp Hydema AS winches Hydraulic type winches
Max. capacity of wire on the trawl winches: 3000 m., wire diameter 26 mm. Owners actually now use 2000 m., wire diameter 26 mm.
4 x 9,2 ts, 45 m/min., sweep line winches
1 x 6.5 ts, 50 m/min., cod end winch
1 x 2.7 ts, 100 m/min. out haul winch
1 x 9.2 ts, 45 m/min., bobbins winch

Gear

Palfinger Marine, PKM 360, SWL 3,0 t.,12 m, deck crane

Anchor

4 tonnes windlass
HHP anchor, 1425 kg. Chain grade NVK 2, Dia. 30 mm. Total length 49,20 m.

Other

COOLING: System for cooling seawater for receiving bin, sorting bin and washing bin installed. For better fish quality.
Pipes in stainless steel from cooling device directly to receiving bin, sorting bin and washing bin.
PROCESSING: 1 x 444S Baader heading and cutting machine
Baader 33 Round-Cut heading
Factory: Painted, etc. in 11/2015 incl. new flooring

Survey Class

DNV + 1A1 Stern trawler E0 Ice (1B) RM(-30 deg C /+15 °C sea)

SPECIAL

NEGOTIABLE

Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
