| Reference Number | 5425
|
| Vessel Type | Trawler
|
| Designed By | Kailis Ship Design
|
| Built By | MG Kailis Shipyards
|
| Year Built | 1983
|
| LOA | 22.5 m
|
| Beam | 6 m
|
| Draft | 2.25 m
|
| GRT | 80.84 T
|
| Construction | Steel
|
| General Description | PRAWN TRAWLER
|
| Engine Details | Cummins KTA19m 364kW
11,000 hours TBC
|
| Horsepower | 488 hp
|
| Auxiliary Engine | Cummins - Stamford generator 65kVA TBC
|
| Electrical | 12V, 24V, 240V
|
| Gearbox | Twin Disc MG516 6:1
|
| Shaft Size | 120 mm
|
| Steering | Double acting hydraulic
|
| Fuel Capacity | 38,000 litres in 8 tanks
|
| Water Capacity | 6,200 litres in 1 tank
Desalination: Citor Reverse Osmosis
|
| Max Speed | 7 knots
|
| Service Speed | 9 knots
|
| Hold/Fishroom | Main Freezer hold 16 Tonne
Snap Freezer hold Capacity: 100 x 13Kg cartons = 1.3 tonne
Compressor -1 x Grasso Vee Series
Compressor - 1 x Bock HAX5/830-4
FDC Units - 1 for the hold
|
| Accommodation | 10 crew
3 x main deck cabins
1 x large cabin below
|
| Galley | Table & seating for 10 crew
Stove
Oven
Microwave
Fridge
Sink
TC/DVD
|
| Facilities | Toilet
Shower
Hot water
Air conditioning all accommodation
|
| Winch Details | 2 x Cod end winches
1 x Tri-net winch
2 x Trawl blocks 350mm
3x trawl blocks 300mm
6x cod end blocks
2x Trawl winches, manual hydraulic spooling. Capstans fitted
2 x snatch blocks
|
| Anchor | Windlass - hydraulic double gypsy with 2x 160mm warping drums
2x 200kg anchors
Chain 2 x 20mm short link
chain
|
| Radio | HF - Codan 9390
VHF - GME TX 3200
ICOM 304
|
| Radar | Furuno 7112
|
| G.P.S. | 2 x Furuno GP 32
|
| Plotter | TBA
|
| Sounders | Furuno FCV 291
Furuno FCV 1100L
|
| Auto Pilot | Saura Keiki
|
| Other | Navigation electronics
Life raft to survey
Life jackets to survey
Bilge pump
|
| Survey Class | Australia USL3B Fishing Offshore
Valid to 5 April 2027
|
| General | This proven design of Prawn Trawler has been successfully operating off the West Australian Coast
and the Gulf of Carpentaria for almost 40 years. This vessel was launched from the Kailis Shipyard in
Henderson WA in 1983 for operations in the Northern Gulf of Carpentaria.
The vessel is powered by a 488 HP KTA19m Cummins main engine and Cummins Genset. The vessel
has now been modified for use in Abrolhos Scallop Fishery.
The Ca-Den III has been maintained and is in AMSA Survey. This vessel can be used for a range of
fisheries including: prawn trawling, drop lining, Shark & Mackerel fishing.
|
| SPECIAL | PRICE REDUCED
|
| Price | AU$ 345,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
