Click on small images to enlarge
|
| Reference Number | 5348
|
| Vessel Type | Barge & Landing Craft
|
| Built By | 1998
Major upgrade & strengthening in Whangarei 2005.
Built to NZ survey requirements
|
| Year Built | 1998
|
| LOA | 81.59 m
|
| Beam | 18.98 m
|
| Draft | 1.8 m
|
| GRT | 1,258 T
|
| NRT | 377 T
|
| Construction | Steel
|
| Construction Details | 2,200 DWT capacity.
Built for carrying sand and aggregate.
16mm deck plating
Reinforced to enable use of diggers etc for unloading 2005
12mm plating forward starboard for main deck heavy machinery access.
10mm plating for other decks.
Main deck 55m x 17m - 10 tonnes m2 reducing to 2 tonnes m2 at deck edges.
Ballast tank 458 tonnes - one tank midships
|
| General Description | SELF PROPELLED INSHORE BARGE 2200 DWT. HAS ACCOMMODATION. REDUCED
|
| Engine Details | 2 x Cummins KTA-19 @ 600hp = 1,200hp
7,000 hours
|
| Electrical | 2 x Perkins Gen sets 90K kVA 14,000 hours
Shore power
|
| Propeller | 2 x 5 blade
2 x 4.5" shafts in oil bath
|
| Fuel Capacity | Main tanks 19,000 litres
Day tank 1,000 litres
|
| Water Capacity | 1,000 litres
|
| Max Speed | 6 knots
|
| Accommodation | 2 x twin berth cabins
|
| Galley | Electric Stove & oven
Stainless sink
Fridge/freezer
Rangehood
Wastemaster
|
| Facilities | separate head
separate shower
|
| Anchor | Electric winch
Anchors & chain to survey
|
| Radio | VHF Uniden MC535
|
| Radar | Furuno 1832
|
| G.P.S. | Furuno
|
| Plotter | Furuno GP-1610CF
|
| Sounders | Furuno GP-1610CF
|
| Auto Pilot | Coursemaster 550
|
| Other | Rudder indicators - Wagner
Loud hailer - Raytheon Ray430
Fire fighting equipment, clothing breathing
|
| Survey Class | MNZ Certificate of Survey
Inshore Limits
Crew 3 Maximum 6
Activities - Work Boat, Dredger
Date of Expiry 12/10/2023
|
| Vessels History | 1998 built in Fiji to NZ survey requirements
2005 major structural upgrade. Reinforcing plates added to decks for heavy machinery. Reinforcing under deck for load carrying. Total of 880 tonnes additional steel added.
All voids Fisholene coated - very good condition. Ballast tanks not coated.
|
| General | A.C. Fire & general service pump.
Ballast pump will empty ballast tank in 40 mins. All A.C. motors have soft starts.
|
| SPECIAL | NEGOTIABLE
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
