| Reference Number | 5264
|
| Vessel Type | Tug
|
| Built By | Malaysia
|
| Year Built | 2006
|
| LOA | 38 m
|
| Beam | 11.8 m
|
| Draft | 3.8 m
|
| GRT | 499 T
|
| NRT | 149 T
|
| Construction | Steel
|
| General Description | AHT OFFSHORE TUG 41 TONNES BOLLARD PULL
|
| Engine Details | 2 x 1600 BHP @ 1800rpm CUMMINS KTA50M2
|
| Auxiliary Engine | 2 x 150 kW CUMMINS 6CTA8.3D(M),
|
| Electrical | 2 x Generators 415V/3 /50
|
| Propeller | 2 x Four blade Fixed Pitch in K/Nozzles
|
| Steering | 2 independent steering
|
| Thruster | Bow thruster - 1 x 3T tunnel thrust driven by CUMMINS 6BTA5.9M3
|
| Bollard Pull | 41.52 tons
|
| Max Speed | 13 knots
|
| Fuel Consumption | Endurance 28 days
Range 5,500 nautical miles @ 10 knots (Approx)
|
| Accommodation | Cabins
2 x 1 berth c/w attached washroom
2 x 2 berth c/w attached washroom
3 x 4 berth c/w attached washroom
(Total 18 pax)
All cabins are centrally air-conditioned
|
| Anchor | 2 x 1020 kg Stockless bower anchors, 10 shackles 32mm diameter chains
Anchor windlass - Electro-hydraulic powered.
Tugger Winch - 1 x 5m tons @ 15m/min
Capstan - 2 x 5t
|
| Other | CARGO CAPACITIES & DISCHARGING PUMPS
Deadweight - 414.68 t
Deck Strength - 5 tons/m²
Clear Deck Area - 150 m²
Fresh Water - 157.18 m3
Fuel Oil - 323 m³
Lube Oil - 7.1 m³
FO pump - 1 x 50m3/hr @ 50m head
FW pump - 1 x 50m3/hr @ 50m head
TOWING / ANCHOR HANDLING EQUIPMENT
Towing/Anchor - 80t Electro Hydraulic double drum c/w wire rope, ME 80THAHTW
Upper & Lower Drum Cap - 52mm dia x 1000m (L)
Line Pull @ first layer 80 tons
Shark Jaws & Towing Pin - Hydraulic operated 150mt SWL
Stern Roller - SWL 120t 4m length.
MARPOL COMPLIANCE
MARPOL I - Oily Water Separator
MARPOL V - Sewage Treatment Plant for 25 men
RADIO & NAVIGATION EQUIPMENT
Communications & Nav aids complied with SOLAS AND FLAG ADMINISTRATION for vessel GRT < 500
GMDSS A3
FIRE FIGHTING EQUIPMENT
Internal
As per SOLAS
CO2Flooding system
CO2 system in engine room & bow thruster compartment
External Fire Fighting + Dispersant System
½ FIFI, engine driven CAT 3412C
Dispersant Boom
LIFE SAVING EQUIPMENT
LSA for 20 men as per SOLAS & Flag administration rule
|
| Survey Class | BV
|
|
