| Reference Number | 4863
|
| Vessel Type | Barge & Landing Craft
|
| Year Built | 2015
|
| LOA | 53.3 m
|
| Beam | 15 m
|
| Draft | 2.4 m
|
| GRT | 1,015 T
|
| Construction | Steel
|
| General Description | LANDING CRAFT. CARGO WEIGHT 500 TONNES. 60 TEU. CARGO OIL 500M3. CARGO WATER 300M3. BV CLASS. AVAILABLE FOR LONG TERM CHARTER OR SALE
|
| Engine Details | 2 x Yanmar 6EY17W 590 kw @ 1350 RPM
Battery start
keel cooled
|
| Horsepower | 1,180 kW
|
| Auxiliary Engine | 3 x diesel engine driven Alternators: 200kW, 415V/3P/50 Hz,
Battery start
keel cooled
Emergency generator on main deck. Cummins 6BT5.9-D(M) 91kW, 415V/3P/50 Hz
|
| Gearbox | 2 x reduction box
|
| Thruster | Electric bow thruster 200 kW
|
| Service Speed | 10 knots
|
| Fuel Consumption | Endurance 1,500 n.miles
|
| Accommodation | 8 persons
|
| Facilities | Air conditioning
En suite
|
| Anchor | 2 x 1,740kg stockless anchors
Electric hydraulic windlass
|
| Other | CARGO CAPACITITIES AND TANKAGE
60 TEU on deck, including 20 reefer sockets
Cargo oil capacity not less than 500 m³
Cargo F.W. Capacity 300 m³
Fuel oil capacity 130 m³
Dirty oil 2 m³
Fuel oil overflow 3 m³
Fuel oil day tanks 5 m³ each
Potable water capacity 70 m³
Grey/black water 10 m³
BOW RAMP
main particulars of the bow door to be as follows:
SWL at least 120 tonnes.
8.0m wide and at least 10 metres long.
CARGO OIL PUMPS
2 x 80 m3/hr , 0.80 MPa
CARGO FESH WATER AND BALLAST WATER PUMPS
2 x 60 m3/hr , 0.65 MPa
NAUTICAL EQUIPMENT
1 Magnetic Compass, reflected type
1 Echo Sounder
1 Speed Log
1 ARPA Radar, X-Band
1 DGPS
1 AIS
2 ECDIS
1 Anemometer
1 Window Wiper
1 Air Horn
2 Rudder Angle Indicator (2)
1 or 2 GPS compass
RADIO EQUIPMENT
2 INMARSAT-C Earth Station
1 GMDSS Control Console with battery charger
1 VHF radiotelephone with DSC
1 Satellite EPIRB
2 Radar Transponder
3 Portable Two-way VHF Radiotelephone
1 NAVTEX
|
| Survey Class | BV notation:
I , + HULL, + MACH, Deck ship, Equipped for carriage of containers, Oil product in tanks, FP>60°C, Unrestricted navigation, +AUT-UMS
|
| General | availabile for sale or long term charter
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
