Reference Number

4399

Vessel Type

Research, Passenger

Built By

Miho Yard
Japan

Year Built

1983

LOA

29.8 m

Length Reg

25.3 m

Beam

5 m

Draft

3.2 m

GRT

62 T

Construction

Steel

Construction Details

Whaleback
Amidships wheel house
3 decks
Large timber fore and aft decks.
Fine bow and big bilge keels

General Description

SERIOUS DEEP SEA SMALL EXPEDITION SHIP. VERY FAST AND EXCELLENT SEA KEEPING ABILITY. WESTERNISED. A GREAT PACIFIC CRUISE VESSEL

Gearbox

Yanmar 2 speed helps maneuvering and towing

Propeller

5 blade bronze

Steering

1)HYDRAULIC/ PNEUMATIC STEERING

Fuel Capacity

15,000 litres

Water Capacity

4,000 litres

Max Speed

13.8 knots

Service Speed

12 knots

Fuel Consumption

Range 3500 miles
1580 litres/day - 66 ltrs/hour giving 230 lies/day including running 60kVA generator.
Engine could probably be derated reducing consumption.

Wheel House

Head room 1.85m

Engine Room

YANMAR
1)T220-ET (MAIN ENGINE- HOURS 15459)
2)X2 6CHL-N W/ SHINKO (60 KW GENSETS A) HOURS 5846 B) HOURS ?)
3)YC2-851 (2 SPEED GEAR BOX)

SPECTRA
1)FARALLON 1800 (WATERMAKER)

HITACHI
1)B135A (DRILL PRESS)

MATSUBARA
1)MG-64B (ELECTRIC/ AIR COMPRESSOR)
2)MG-64A (DIESEL/ AIR COMPRESSOR)

DAITO
1)FIRE/ WATER/ OIL PUMPS

TAIKO KIKAI
1)UST-01 (OILY WATER SEPARATOR)

Hold/Fishroom

20 cbm in 3 below deck holds plus fore-peak.

Accommodation

2 x 6 berth cabins
2 x 2 berths cabins
Head room 1.95m

Galley

Full stainless steel facilities
Large stainless steel stove
Fridge
Head room 1.95m

Facilities

1)STAINLESS STEEL SINK
2)STAINLESS STEEL GAS OVEN/ STOVE
3)STAINLESS STEEL REFRIGERATOR/ FREEZER
4)3X MARINE AIR SYSTEMS (WATER COOLED AC UNITS)

Winch Details

Sample winch 2,000m
Hydraulic & electric capstans

Cargo Winch

HIAB 4.5 t

Anchor

120kg
350kg
19kW hydraulic power pack

Other

FURUNO
1)MFDBB (MULTI FUNCTION DISPLAY) TYPE MPU-001
2)NAVpilot-500 (AUTO PILOT)
3)FA-50 (CLASS B AIS TRANSPONDER)
4)DFF1 (NETWORK SOUNDER)
5)FAX 30 (FACSIMILE RECEIVER)
6)GP-330B (GPS RECEIVER)
7)DRS 12A (RADAR SENSOR)
8)FCV-582 (COLOR VIDEO SOUNDER)

JRC
1)NRD-92 (RECEIVER)
2)NCE-8354 (CONTROL BOARD)
3)JLR-6000 (GPS)
4)PUBLIC ADDRESSER

ICOM
1)IC-M802 (SINGLE SIDE BAND RADIO)
2)IC-M304 (VHF MARINE RADIO)
3)AT-140 (AUTOMATIC ANTENNA TUNER)

TERASAKI
1)WATCH FREE SYSTEM (ENGINE ROOM MONITOR)
2)SG-6731 (CONTROL CONSOLE)

IRIDIUM
1)OPEN PORT (SAT PHONE/ DATA PORT)

TOKYO KEIKI
1)PR-100 GM-10 (GYRO COMPASS)

TRIMBLE
1)TNL7005 (GALAXY INMARSAT-C/GPS

WHITE-WESTING HOUSE
1)12000 BTU/H (AC UNIT)

IBUKI KOGYO CO. LTD
1)MOTOR SIREN

MARETRON
1)WSO100 (ULTRASONIC WIND/ WEATHER STATION

UNIDEN
1)OCEANUS (VHF RADIO)

AUTECH
1)4 CH MPEG DVR W/ 4 CAMERAS

SANSHIN DENGU MFG CO. LTD
1)CX-4020H (XENON LAMP TYPE SEARCH LIGHT. MAX LUM. 65X10 6CD)

NUNOTANI SEIKI SEISAKUSHO CO. LTD.
1)T150VA/ T1390 (MAGNETIC COMPASS)

GME
1)MT403FG-E999F (CLASS 2 GMDSS CAT 1 + GPS EPIRB)

ACR
1)PATHFINDER 3 (SART)

NEI
1)CM300-1EB (CLEAR VIEW SCREEN)

OTHER
1)3 LED DISPLAYS FOR NAVNET SYSTEM
2)GS SP-35-20B (BATTERY CHARGER)

DECK GEAR
1)HYDRAULIC ANCHOR/ WINDLESS
2)3 ANCHORS
3)2 RFD SURVIVA (SOLAS A, 25 PERSON, LIFE RAFT)
4)HIAB CRANE (? TONS)
5)SOLAR PANEL FOR RADIO BATT.

Vessels History

Built for Japanese Government for fisheries control in northern Japan. Was used on an average of 3 weeks a year for mainly fisheries control in northern Japan with up to 7 officers.

General

Well insulated and ventilated making it suitable for climate extremes.
The bilge keels add greatly to on-board passenger comfort.
VESSEL APPEARS TO BE IN EXCELLENT CONDITION

Price

US$ 350,000.00 Plus GST and /or Taxes if any.

Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
