Click on small images to enlarge
|
| Reference Number | 4217
|
| Vessel Type | Work Boat, Tug, Netter, Lobster / Potter
|
| Built By | Marco, Australia
|
| Year Built | 1992
|
| LOA | 18.5 m
|
| Length Reg | 17.6 m
|
| Beam | 5.9 m
|
| Draft | 1.4 m
|
| GRT | 36 T
|
| NRT | 24 T
|
| Construction | Timber
|
| Construction Details | Ply on hard wood frames
Very big flush deck
|
| General Description | AN AWESOME VESSEL WITH TOWING SURVEY. VERY VERSATILE
|
| Engine Details | 2 x Scania DI12 EMS S6/PDE 650hp new June 2006
|
| Horsepower | 1,300 hp
|
| Auxiliary Engine | Onan 3 cyl (new 2002)
|
| Electrical | 6.5 kVA (new 2002)
2400W Inverter/battery charger
|
| Gearbox | 2 x Twin Disc MG5/51140A 2.04:1 (new June 2006)
|
| Propeller | twin 36" x 32"
3" shafts (new June 2006)
|
| Shaft Size | 3 inches
|
| Fuel Capacity | 5600 litres in 4 tanks
|
| Water Capacity | 800 litres in one tank
|
| Max Speed | 20 knots
|
| Service Speed | 15 knots
|
| Fuel Consumption | Approx 27 LPH per engine on an average cray fishing day
15 knots Steaming at 1850 rpm 67 lph per side.
|
| Wheel House | Forward
|
| Engine Room | Mid ship
|
| Hold | 1 T
|
| Hold Type | Live Well
|
| Hold/Fishroom | dry hold size 4.00m wide x 3.00 m x 1.50m high. Space could be used for accommodation or a fish hold
|
| Accommodation | 7 berths
|
| Galley | Fridge
Combination Microwave/grill/bake oven
Electric cook top
|
| Facilities | Shower, toilet,
hot water
|
| Pot Hauler | Hydraulic with Australian tipper.
SS craypot davit
|
| Gear | Hydraulic Luff Hauler (large)
|
| Anchor | Hydraulic winch
2 anchors
|
| Radio | VHF - Icom
SSB - Furuno 1550
|
| Radar | Koden MDC-104 48 nm colour LCD radar - new August 2007
|
| G.P.S. | Furuno GP3100 GPS/Plotter.
Furuno GP32
|
| Sounders | Furuno FCV381 88/200
|
| Auto Pilot | Furuno FAP/55
|
| Other | Tape stereo
TV
DVD
6 man life raft (new October 2010)
|
| Survey Class | New Zealand Coastal FV Class X.
Towing 100 miles
Expires May 2014
|
| Vessels History | Brought to NZ November 1995.
Used for lobster fishing and as a tow boat.
June 2006 hull & decks painted inside and out. New engines & gearboxes. New dash board in bridge.
|
| General | Has towing post.
AN AWESOME VESSEL
|
| Price | NZ$ 390,000.00
Plus GST and /or Taxes if any.
|
|
