| Reference Number | 4186
|
| Vessel Type | Barge & Landing Craft
|
| Built By | Malaysia
|
| Year Built | 2010
|
| LOA | 45.5 m
|
| Beam | 10.9 m
|
| Draft | 2.4 m
|
| GRT | 488 T
|
| Construction Details | Deck area - 230m2
Deck strength - 5mt.sqm
Ramp door - 7500mm x 6920mm
Design loading - 5t/m2
Lashing lugs - 24
Reefer point 2 x 415/3/50
|
| General Description | LANDING CRAFT 330 TONNES DECK CARGO 256 TONNES FUEL CARGO, 336m3 FRESH WATER CARGO
|
| Engine Details | 2 x Caterpillar 3412 720hp @ 1800rpm
|
| Horsepower | 1,440 hp
|
| Auxiliary Engine | 2 x Cummins 6BT5.9D(M) 80kW 415/3/50
|
| Propeller | 2 x fixed pitch
|
| Steering | Electro-Hydraulic 2 x 2.0T-M at 35Deg steering angle
|
| Thruster | Tunnel type - 3 tonnes
|
| Fuel Capacity | Fuel oil - 42 tonnes
CARGO fuel - 256 tonnes
Endurance 30 days
|
| Water Capacity | Fresh Water - 98 tonnes
CARGO fresh water - 336m4
BALLAST TANK SW/FW - 83m3
|
| Max Speed | 11 knots
|
| Engine Room | MARPOL 1 1 X Oily water separator
MARPOL IV 1 x Sewage plant for 25 men
|
| Accommodation | Fully air-conditioned 20 berth
Chiller/ Freezer
|
| Anchor | Bow anchor - 2 x 900kg Stockless with 8 shackles anchor chain
Windlass - 1 x Electro Hydraulic twin gypsy
c/w 2 wrapping heads c/w hydraulic-electro power pack
|
| Other | NAVIGATION AND COMMUNICATION
Communication equipments complied with GMDSS for A3 for vessel.
SAFETY AND FIREFIGHTING EQUIPMENT
In compliance with SOLAS, & Class requirement &/
requirement of Flag administration.
LSA for 24 men
|
| Survey Class | LR
|
| Price | US$ 3,300,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
