| Reference Number | 4178
|
| Vessel Type | Liners - Bottom & Surface
|
| Built By | Iisiku Shipyard Company Limited
Japan
|
| Year Built | 1978
|
| LOA | 33.1 m
|
| Length Reg | 26.65 m
|
| Beam | 6.98 m
|
| Draft | 2.3 m
|
| GRT | 98 T
|
| NRT | 29 T
|
| Construction | Steel
|
| General Description | EX JAPANESE LONG LINER - LAID UP FOR SALE AS IS WHERE IS.
|
| Engine | Niigata
|
| Engine Details | 6M26ZGR 53470. Air start
New heads February 2007
260 bore X 400 Stroke 350ps @ 400 rpm.
|
| Horsepower | 268 kW
|
| Auxiliary Engine | Cummins Bowman Generator
2007 Sanbo 150kVA Generator
Perkins 4 Cylinder 50 kVA Emergency Generator
|
| Gearbox | Niigata Twin disc
|
| Propeller | 6 Feet 4 Blade
|
| Steering | Hydraulic
|
| Fuel Capacity | 61.47 Tonnes. 7 Tanks
|
| Water Capacity | 15.31 Tonnes. 3 Tanks
|
| Max Speed | 9 knots
|
| Service Speed | 8 knots
|
| Fuel Consumption | Duration 80 Days
400 to 100 litres per day
|
| Wheel House | Mid Ship
|
| Engine Room | Aft
|
| Hold | 40 T
|
| Hold Type | Freezer
|
| Hold/Fishroom | Front hold -30degC. (used to be -60)
4 x ice holds
Bait Freezer - blast
Bait hold below
(total holds = 7)
|
| Freezer Plant | Starboard compressor drives front hold and blast freezer
|
| Accommodation | 11 Berths
Masters Cabin 2 berths
Engineers cabin single berth
|
| Galley | Stove, Fridge, Freezer
|
| Facilities | Hot Water
Toilet
Shower
Bath (salt water)
|
| Pot Hauler | Hydraulic Auto Stop
|
| Line Hauler | Hydraulic Bottom Long Line
|
| Gear | Mustad auto liner
No Hook baiter & separator
No backbone, hooks snoods etc
|
| Anchor | Winch & 3 x Anchors
|
| Radio | VHF x 2,
|
| Radar | Furuno 1941 Mark II Furuno GaAs 8 Tone Daylight Display
Viewsonic Radar with chart plot
|
| G.P.S. | C-Plot
|
| Plotter | Furuno GP1810
|
| Sounders | Furuno FCV 291 colour video
|
| Auto Pilot | Tokyo Keiki Gylot
|
| Other | Inmarsat- Icom AT140
Laptop Computer
Saura Keiki magnetic compass
Helm indicator
Furuno D-FAX - 207
Seafax Weather Fax
|
| Survey Class | Shaft due march 2011
Last ultra sound and shaft inspection July 2007
|
| Vessels History | First registered in NZ 1997.
Built as raised forecastle squid jigger vessel. Squid gear removed, converted into Tuna fishing with Mustad gear.
|
| General | Vessel laid up in Wellington.
Engines run up monthly.
DETAILS NOT CONFIRMED
CONTACT US FOR INFORMATION
Price idea NZ $50,000.00
|
| SPECIAL | OFFERS
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
