| Reference Number | 4014
|
| Vessel Type | Liners - Bottom & Surface
|
| Designed By | Watanabe, Japan
|
| Built By | Watanabe Shipbuilding Co Japan
|
| Year Built | 1980
|
| LOA | 34.41 m
|
| Length Reg | 27.35 m
|
| Beam | 6.2 m
|
| Draft | 2.43 m
|
| GRT | 119 T
|
| NRT | 86 T
|
| Construction | Steel
|
| General Description | MULTI-PURPOSE LONG LINE/POT LINE VESSEL. DEEP SEA CRAB, LOBSTER, PRAWNS
|
| Engine Details | Yanmar T220 Rebuilt February 2003
|
| Horsepower | 1,000 hp
|
| Auxiliary Engine | Perkins MLS 70hp rebuilt June 2002
|
| Electrical | Mitsubishi TEW-6032-6 250kVA alternator driven by main
|
| Gearbox | Japan Y 850 Hydraulic
|
| Propeller | 800 Variable Pitch
|
| Shaft Size | 195 mm
|
| Steering | Electric XS 4S, AC 220
|
| Fuel Capacity | 160,000 litres 11 Tanks + Hold #2
DURATION 90 DAYS AT SEA
Standby 250 litres per day
Fishing/Idling 800 litres per day
Steaming 1,800 litres per day
|
| Water Capacity | 12 Tonnes 3 Tanks
Water maker 5 tonnes per day
|
| Max Speed | 9.5 knots
|
| Service Speed | 8.5 knots
|
| Fuel Consumption | Steaming 1800 LPD. Fishing/idling 800 LPD. Standby 250 LPD
DURATION AT SEA - 4 months
|
| Wheel House | Middle
|
| Hold | 210 m3
|
| Hold Type | Ice, Freezer
|
| Hold/Fishroom | Hold #1 30m3 cold water
Hold #2 60m3 Freezer - 45C
Hold #3 120m3 Freezer -45C
|
| Freezer Plant | 2 x compressors 55kW + 19kW.
Air Blast to -60 degrees C. Daily capacity 10T
|
| Accommodation | 16 Berths
|
| Galley | 2 x Stove. 3 x Fridge
|
| Facilities | Toilet
Shower
Hot water
Washing machine
TV
Video
|
| Pot Hauler | Hydraulic 1.5 T
|
| Line Hauler | Hydraulic
|
| Gear | MULTIPURPOSE - equipped for
1. Variable depth long line
2. Variable (up to 460 metres) pot line (with up to 25 pots per line) suitable for fishing lobsters, scampi, crab & prawns
|
| Cargo Winch | 2.5 T
|
| Anchor | 2 x Winches Electric
2 x Anchor
|
| Radio | SSB Furuno 1552
VHF Uniden MC615
|
| Radar | Furuno FR 810D
|
| G.P.S. | GP 8000 MK2,
|
| Plotter | GPS Navigator
|
| Sounders | Furuno FCV1000
|
| Auto Pilot | Yes
|
| Other | Satcom C / Inmarsat C TNT 7001
Sat 406 radio Beacon
Water temp guage Furuno
Determining factor fish type Furuno
|
| Survey Class | Four year completed 2007
|
| General | 2 x SOLAS liferafts 10 + 16 people
Rescue boat (German 2008)
|
| Price | NZ$ 850,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
