| Reference Number | 3787
|
| Vessel Type | Netter
|
| Designed By | Alomarine
|
| Year Built | 1994
|
| LOA | 15.9 m
|
| Beam | 5.5 m
|
| Draft | 2.648 m
|
| Construction | Aluminium
|
| Construction Details | Welded Aluminium
|
| Engine | Caterpillar
|
| Engine Details | CAT 3408 8cyl Turbo Diesel
|
| Horsepower | 450 hp
|
| Auxiliary Engine | Kubota 3cyl
12kVA
|
| Gearbox | Twin Disc MG5114-A
Reduction: 2.5:1
|
| Steering | Hydraulic
|
| Fuel Capacity | 2x Fuel Tanks
3,200 Litres total
|
| Water Capacity | 1x tank
120 Litres approx
|
| Hold/Fishroom | 4x non-refrigerated holds, average 5 tonne each.
Carry ice slurry & anti-bacterial solution to protect caught sardines.
Ideal catch is 15 tonnes
|
| Accommodation | 4x Single Beds
Layout Forward
|
| Galley | Microwave & Ronson Grill
Westinghouse 140lt Fridge/Freezer
Sink
Dining area with seating for 5, water urn
|
| Gear | 350 metre long net in good condition
|
| Radio | AWA HF, GME Electrophone VHF
|
| Radar | Furuno 1721
|
| G.P.S. | Furuno GP30
|
| Plotter | TMQ
|
| Sounders | Furuno Colour FCV581
|
| Auto Pilot | Course Master 400
|
| Other | Computer - TMQ Chart Plotting system
Stereo - Radio Cassette
Plastimo 100mm Offshore Compass
Kodan Colour Sonar
Furuno Digital Temp T200
Rudder Angle Indicator
4 Man RFD
|
| Survey Class | Class - 3B
WA to 100NM offshore
Shaft due June 2008
|
| General | Single chine monohull, raised foredeck, forward below deck cabin with half height deckhouse, midship accom and wheelhouse, midship engine compartment.
Forward & aft ice holds with raised coamings
flush deck across ways port & stbd of ice holds
69mm stainless steel prop shaft
|
| Price | AU$ 500,000.00
Plus GST and /or Taxes if any.
|
|
Plus GST and /or Taxes if any. All information is provided in good faith and is accurate to the best of our knowledge AT DATE OF LISTING. Buyers should verify information, by inspection, prior to purchase. We accept no responsibility for errors.
|
